Cub Cadet 3000 Series

6 - 13
Cub Cadet 3000
The steering control is now ready for test and installa-
tion.
Torque plug to 15 in. lbs.
Install the check ball or optional relief valve check as
shown here.
Install the end cap retaining cap screw and tighten in
a crisscross sequence. Torque to 140-160 in. lbs.
Figure 52.
Figure 51.
Figure 50.
Figure 49.
