15
Control Assembly -
Parts List for Figure 8
Ref.
No. Part No. Description Qty
.
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin .125 Dia x 1.0 6 28 01005770 Side Panel, Control, Right 1
2 00011861 Hex Cap Screw, 3/8-16, 2.5 4 29 01010176 Mounting Handle 2
3 00022560 Hex Nut, 3/8-16, Lock Flange 31 30 01003011 Lever, Safety Switch 2
4 00060078 Grease Fitting, 1/4-28 x 3/16 2 31 01004889 Control Panel, LH 1
5 00013131 Hex Cap Screw, 1/4-20, .75 2 32 01004890 Control Panel, RH 1
6 01000369 Hex Cap Screw, 3/8-16, 1.25 10 33 02000164 Switch Mounting Bracket, Lapbar 2
7 01000372 Carriage Bolt, 3/8-16 x .75 17 34 01001968 Link Mounting Control Shaft, Bracket 1
8 00012152 Lock Hex Nut, 1/4-20 2 35 01003199 Stop, RH 1
9 01000450 Hex Jam Nut, 3/8-24 4 36 01003200 Stop, LH 1
10 01000451 B/Joint, 3/8-24, Right Hand Female 4 37 01003591 Holder Shaft, Park Brake 4
11 01000628 Screw, TT, 1/4-20, 0.5, Hex Index Washer 19 38 02000162 Decal , Warning & Throttle 1
12 01000635 Nut, Lock, HexFlange, 5/16-18 7 39 02000163 Decal, Warning & Key Switch 1
13 00013406 Hex, Cap Screw, 5/16-18 x 3/4 4 40 01003451 Decal Right Hand Control 1
14 01000960 Belle Washer, .325 x .930 x .045 2 41 01003452 Decal, Left Hand Control 1
15 01002990 Belle Crank Assembly, includes: 2 42 01003561 Nut, Hex, Center Lock, M8 x 1.2 4
16 01000308 Bushing 4 43 00022223 Grip, 1 2
17 01001727 Cylinder Return to Neutral 2 44 750-3119 Spacer, .406 ID x 1.00 OD x .38 4
01003044 Hub Assy, Control LH Bearing 1 45 01007359 Lapbar Handle, One Position 2
18 01004265 Bearings 2 46 01005870 Side Label, CCC 2
19 01003045 Hub Assy, Control RH Bearing 1 47 01005784 Bracket Assembly, Mount Dampener 2
01004265 Bearings 2 48 01004003 Flat Washer, 5/8 Nylon 8
20 01002511 Nut, 3/8-16, Jam 2 49 01004127 HHCS, 3/8-16, 3.00 2
01002980 Shaft Mounting Belle Crank 2 50 00009812 Flat Washer, 5/16 4
21 01002982 Rod Connector 3/8 OD x 10.125 2 51 00012226 Grease Fitting, 90°, 1/4-28 2
22 01002983 Rod Connector, 3/8 OD x 4.28 LG LH 1 52 00013092 HHCS, 5/16-18 x 1.0 1
23 01002984 Rod Connector, 3/8 OD x 8.06 LG RH 1 53 01006350 Shaft Collar, .625 ID, 1.00 OD, .438 Lg 2
24 01002986 Nut, 3/8-24, Jam, LH Third 4 54 01003947 U-Nut, 3/8-16 x .75 2
25 01002987 B/Joint, 3/8-24, LH Female 4 55 01005851 External Lock Washer 2
26 01002988 Screw, Shoulder Control Rod 2 56 01000629 Screw, TT, 1/4-20, 0.75, Hex Index
Washer
1
27 01005769 Side Panel, Control, Left 1
