Cub Cadet 53AB5BBP750 - Chassis and Frame Assembly; Chassis and Frame Assembly Parts List

26
Frame Assembly- Figure 17 and Parts List
Ref.
No. Part No. Description Qty.
1 00022560 Hex Nut, 3/8-16 Flange Lock 7
2 01000372 Carriage Bolt, 3/8-16 x .75 Long 7
3 01001713 Bracket Assembly, Frame, Front 1
4 01001617 Frame Assembly 1
5 02000129 Cover, Hydro Fan 2
6 01008225 Push Retainer, 3/8" 4
1
3
2
4
5
6
GD: 01007401-12/02/04
