25
Assembly Pump Left Hand- Figure 16 and Parts List
Ref.
No. Part No. Description Qty.
1 01000635 Lock Nut, Hex Flange 5/16-18 4
2 01001807 Gear, Spur, 14T 1
3 01001808 O-Ring, 2.00 x .070 1
4 01001809 Parking Brake Lever 1
5 01001995 Pin, Spirol, 3/16 x 1.25 HD 1
6 01001545 Pump 1
7 01007264 Transmission Assembly 1
8 01000548 Rib Neck Stud, 1/2-20 4
9 01004161 Set Screw, 5/16 - 24 x 1.25 1
4
7
8
1
6
2
3
5
GD: 01007266-07/03/01
Set Screw Position
