5
50" Formed Cutter Deck - Parts List for Figure 1
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, .125 Dia x 1.0 2 36 01008593 Idler Arm Assembly 1
2 00008495 Capscrew, 3/8-16 x 1-3/4 1 37 01008620 Self Tapping Screw 5/16-18 x .750 6
3 00012226 Grease Fitting, 1/4-28, 90° 1 38 00012428 Hex Nut, 1/2-13, Insert Lock 4
4 00012470 Cable Tie, 3/16 x .05 x 7.4 1 39 01009102 Hinge Pin, .375 x 14.06 1
5 00013406 Hex Cap Screw, 5/16-18 x 3/4 1 40 01009253 Flat Washer, .390 x 1.5 x .134 1
6 00022560 Hex Nut Flange lock, 3/8-16 12 41 01009705 Chute Deflector 1
7 00027279 Nut 7/16-14, Nylock 1 42 01010168 Hi-Lift Blade, 17.9 3
8 00034167 Hex Cap Screw, 3/8-16 x 5.00 1 43 01010173 Spacer, .39 ID x .875 OD x 1.00 1
9 01005011 V-Belt, B-Section 1 44 02000407 Deck Assembly 50" 1
10 00060078 Grease Fitting, 1/4-28 x 3/16 1 45 02000402 Flange Hex Nut, 3/4-16 3
11 01009635 Extension Spring, 1.0 OD x 5.00 1 46 02000417 Spring Tension Rod Assembly 1
12 01000372 Carriage Bolt, 3/8-16 x .75 Lg 5 47 02000481 Hex Cap Screw, 3/4-16 x 8.00 1
13 01000375 Roller Pin, 1/2 Dia x 7.31 Lg 1 48 02000626 Left Hand Belt Cover 1
14 01000385 Front and Rear Roller 3 49 02000667 Right Hand Belt Cover 1
15 01000387 Torsion Idler Spring 1 50 618-3129B Blade Spindle Assembly 3
16 01000393 Flat Washer, .469 ID x .875 OD x .105 1 51 01004109 Tension Rod Stop Bracket 1
17 01000628 Screw, TT, 1/4-20 x .5, Hex Index Washer 7 52 703-3511 Finger Guard 1
18 01000635 Hex Flange Lock Nut, 5/16-18 1 53 710-1852 Spindle Bolt 3/4-16 x 5.37 2
19 01000723 Flat Washer, .406 ID x 1.0 OD x .105 3 54 712-0641 Hex Nut, M16-1.5 2
20 01001169 Short Roller 2 55 721-04041 Adaptor, Water Nozzle 1
21 01001745 Pin, 5/8 Dia x 1.2 Lg 4 56 703-1890 Deck Wheel, 5.00 Dia. 2
22 01002010 Carraige Screw, 3/8-16 x 1.25 1 57 736-0760 Lock Washer, 17 x 23.8 x 1.9 2
23 01002564 Spacer, .76 ID x 2.00 OD x .477 3 58 737-04003B Nozzle, Deck Water 2
24 01003123 Spacer, .812 ID x .218 Lg. 2 59 737-3000 Grease Fitting 3
25 01003245 Spacer, .39 ID x .625 OD x 2.75 1 60 738-3056 Shoulder Screw .498 x 1.53 2
26 01003253 Torsion Spring 1 61 738-3172 Shoulder Screw .68 x 2.11 1
27 01004081 Flat Pulley with Flanges 1 62 748-3065 Spindle Spacer 6
28 01004101 Idler Pulley, 4.06 OD with Deep Flange 1 63 750-3119 Spacer .406 ID x 1.00 OD x 0.38 1
29 01004118 Shoulder Screw, .50 x .27 Lg; 3/8-16 1 64 02000653 V-Belt, 1/2 x 91 LG 1
30 01004751 Roller Pin Rod 1 65 02000668 Skirt, Center, 50" 1
31 01005201 V-Pulley, 4.75 OD 1 66 02000669 Skirt, Right Hand, 50" 1
32 01006181 Idler Arm Assembly, Flat Top Bearing 1 67 783-04470 Chute Mounting Bracket 1
33 01006535 Pulley, A Sect x 4.90 3 68 777S30145 Decal, Danger Hands & Feet 1
34 01006680 Spacer, .760 ID x 1.75 OD x 1.969 1 69 02000813 Spindle Plate 3
35 01008456 Spacer .760 ID x 1.5 OD 1 70 02000762 Self Tapping Screw 5/16-18 x 1.00 12
To Next Page
