Brake Assembly
- Parts List for Figure 3
Ref.
No. Part No. Description Qty.
1 00006131 Hex Nut, 3/8-16 4
2 00009678 Clevis Pin, 3/8 x 1, 1/8 2
3 00011888 HHCS, Standard, 3/8-16 x 3-1/2 1
4 00021955 Yoke, 3/8-16, Female 2
5 00021956 Hair Pin, 3/8"-1/2" 2
6 00012226 Grease Fitting, 1/4-28, 90° 1
7 01000100 Shoulder Nut 2
8 00022560 Nut, Flange Lock, 3/8-16 3
9 01000628 Screw, TT, 1/4-20 x .5, Hex Index
Washer
4
10 01000723 Flat Washer, .406 ID x 1.0 OD x .105 4
11 01000872 Flat Washer, .411 x 1.25 x .100 2
12 01002751 Spacer, .39 ID x .63 OD x 1.75 1
13 01002771 Hair Pin, INT .072 x 1.12 Lg. 4
14 01002772 Spacer, .375 x .50 x 1.02 Lg. 1
15 01002980 Mounting Shaft, Bellcrank 1
16 01003591 Holder Shaft, Park Brake 2
17 01003410 Rod Connector, 3/8 OD x 33 2
18 01003593 Brake Bracket 1
19 01008886 Rod Brake, Connect To Handle 1
20 01003417 Connecting Rod, 3/8 OD x 5.75 2
21 01003595 Weldment, Brake Handle 1
22 01003574 Brake Spring, Neutral 2
23 01003575 Brake Spring, Force 2
24 01003576 Brake Hose, Center 2
25 01003716 Grip, Park Brake 1
26 01003730 Weldment Hub, Brake Bearing
Includes:
1
01004265 Bearings 2
27 01002511 Jam Nut, 3/8-16 2
28 00012173 Lock Nut, Nylon Insert, 3/8-16 2
29 01006350 Shaft collar, .625 ID x 1" OD x .438 Lg 2
30 01008889 Park Brake Mounting Bracket 1
To Next Page
