OIL AND FUEL
USING THE RIGHT OIL
Use a high-quality SAE 30 weight oil of API (American Petroleum
Institute) service class SJ. DO NOT use dirty oil. Failure to use clean
oil of the correct type can cause premature engine wear and failure.
ADDING OIL: INITIAL USE
NOTE: This unit was shipped without oil in the crankcase. Oil must
be added before starting the unit.
NOTE: This unit comes with a 3.04 fluid oz. (90 ml) bottle of oil.
1. Unscrew the top of the oil bottle. Remove the paper seal.
Reinstall the top of the oil bottle.
2. Remove the cap from the oil bottle. Cut the tip off the funnel
spout (Fig. 4).
3. Set the unit on a flat, level surface. Tip the unit back so that
the handles touch the ground and the engine is in a horizontal
position (Fig. 5).
4. Unscrew the oil fill plug (Fig. 6).
5. Pour the entire bottle into the oil fill hole (Fig. 6). DO NOT
overfill. Refer to Checking the Oil Level.
NOTE: Never add oil directly to the fuel tank. This unit has a four-
cycle engine. DO NOT mix oil with gasoline.
6. Wipe up any oil that may have spilled.
7. Reinstall the oil fill plug.
NOTE: Make sure the O-ring is in place on the oil fill plug (Fig. 6).
NOTE: Save the empty oil bottle. Use the bottle to measure the
correct amount of oil during future oil changes.
Fig. 5
Fig. 4
Funnel Spout
WARNING:
OVERFILLING THE CRANKCASE MAY
CAUSE SERIOUS PERSONAL INJURY. Check the oil level
before each use. The importance of maintaining the proper
oil level cannot be overemphasized. Change the oil
according to the Maintenance Schedule.
Fig. 6
Oil Fill Plug
Oil Fill Hole
O-Ring
Oil Fill Plug
Fuel Cap
