Chassis
510
Front Disc Brake Components
No.
Part Name Qty Remarks
Removing the Front Brake Line
Attachment Hardware
1
Belt 3 (L – 150) 2
2
Belt 4 (L – 200) 4
3
Belt 6 (L – 150) 4
4
Bolt 6mm X 30mm 1
5
Bolt 6mm X 20mm 1
6
Disc brake line clip 3
7
Flange bolt 6mm X 20mm 4
8
Wire clip fixed plate brake 2
9
line assembly 1
