Specifications
2-21
CHASSIS TIGHTENING TORQUES
Part to be Tightened
Thread
Size
Torque
Nm
Torque
Ft Lbs
Rubber connecting bracket 1(or 2) and frame 10 mm 52 37
Engine and Rubber connecting bracket 2 (front) 10 mm 52 37
6 mm 10 7.2
Engine and Rubber connecting bracket 1 (rear) 8 mm 33 24
6 mm 10 7.2
Rear upper arm and frame 10 mm 45 32
Rear lower arm and frame 10 mm 45 32
Rear knuckle and rear upper arm 10 mm 45 32
Rear knuckle and rear lower arm 10 mm 45 32
Rear shock absorber and frame 10 mm 45 32
Rear shock absorber and rear lower arm 10 mm 45 32
Rear Balancing pole and frame 8 mm 32 23
ball head of Rear Balancing pole and Rear Balancing pole 10 mm 56 40
ball head of Rear Balancing pole and rear lower arm 10 mm 56 40
Differential gear case and frame 10 mm 55 40
Differential gear case filler plug 14 mm 23 17
Differential gear case drain plug 10 mm 10 7.2
Universal joint yoke and drive pinion gear 14 mm 62 45
Differential motor and differential gear case cover 8 mm 13 9.4
Differential gear case cover and differential gear case 8 mm 25 18
Rear driving axle gear case and frame 10 mm 70 51
Rear driving axle gear case filler plug 20 mm 23 17
Rear driving axle gear case drain plug 10 mm 20 14
Ring gear bearing housing and final drive gear case 8 mm 23 17
10 mm 40 29
Ring gear stopper nut 8 mm 16 11
Bearing retainer and final gear pinion gear bearing
housing
65 mm 170 125
Coupling gear and final drive pinion gear 12 mm 80 58
Front upper arm and frame 10 mm 45 32
Front lower arm and frame 10 mm 45 32
Front shock absorber and frame 10 mm 45 32
Front shock absorber and front upper arm 10 mm 45 32
Steering shaft assembly and steering Cross member 8 mm 22 16
Steering assembly and steering Cross member 8 mm 22 16
Steering assembly and frame 10 mm 48 35
Steering shaft assembly and frame 8 mm 21 15
Steering wheel and steering shaft assembly 12 mm 35 25
Steering knuckle and front upper arm 12 mm 30 22
