Cub Cadet GT1554 Parts Manual

-9-
FRAME
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 683-004173
777I22240
Frame Assembly, Lower
Graphic, Bypass Rod
1
1
2 710-0607 Screw, Hex Wash. Hd. Tapp, 5/16-18 x .5 5
3 710-0642 Screw, Hex Wash. Hd. Tapp, 1/4-20 x .75 1
4 710-0726 Screw, Hex Wash. Hd. Tapp, 5/16-12 x .75 13
5 710-3005 Screw, Hex Cap, 3/8-16 x 1.25 GR5 2
6 712-04064 Nut, Flange Insert Lock, 1/4-20 GRF 1
7 712-04065 Nut, Flange Insert Lock, 3/8-16 GRF 4
8 732-04035 Spring, Compression, 1.28 OD x 3.125 Lg 2
9 736-0222 Washer, Lock, Ext 1/4 1
10 738-0143 Shoulder Screw, 3/8-16 2
11 738-04058 Spacer, Shoulder, .38 x 1.0 x .70 2
12 747-04121A Rod, Battery Holddown 1
13 783-04329A Bracket, Seat Frame 1
14 783-04710
777I22241
Frame, Upper
Graphic, Fuel
1
1
15 783-0693 Bracket, Axle 1
16 783-0726D Bracket, Pivot, Support RH 1
17 783-0727C Bracket, Pivot, Support LH 1
18 783-0728 Bracket, Pivot, Bar 1

Cub Cadet GT1554 Specifications

General

Engine Brand	Kohler
Transmission	Hydrostatic
Drive	2WD
Deck Material	Steel
Engine Type	4-Cycle
