described on the following pages.
Read and follow all safety rules and
instructions in this manual, including the entire
this machine. Failure to comply with all safety rules
and instructions may result in personal injury.
Throttle / Choke Control
The throttle/choke control is located on the right
the speed of the engine and, when pushed all the
way forward, closes the choke for cold starting.
When set in a given position, the throttle will
maintain a uniform engine speed.
NOTE: When operating the tractor with the
cutting deck engaged, be certain that the
throttle/choke control is always in the FAST
(rabbit) position.
Brake Pedal
The brake pedal is located on the left
front side of the tractor along the
running board. The brake pedal can be
used for sudden stops or setting the
parking brake.
NOTE: The brake pedal must be fully
depressed to activate the safety
interlock switch when starting the tractor.
Seat Adjustment Lever
The seat adjustment lever is located under the front of the
seat. To adjust the seat forward or backward, slide the seat
adjustment lever to the left and reposition the seat to the desired
adjustment lever to lock the seat in place. Refer to the Assembly
and Set-Up section of this manual for more detailed instructions.
Controls and Features
