13se c t i O n 2 — as s e M b l y & se t -up
Mechanical Suspension Mechanism
To adjust the mechanical suspension mechanism, there
is a lever on the front of the seat with an orange colored
indicator arrow and guage.
2.
center of the seat, flip the lever out towards the right and
pull upward on the fold-out lever and “pump up” to increase
orange-colored indicator on the guage to achieve your
exact weight setting.
Lumbar Support
the lumbar support from the top portion of the seat, to the
lower portion and off. Rotate the knob to set the support to
the desired area.
Connecting the Battery Cables
CALIFORNIA PROPOSITION 65 WARNING:
contain lead and lead compounds, chemicals known
reproductive harm. Wash hands after handling.
CAUTION: When attaching battery cables, always
For shipping reasons, both battery cables on your equipment
may have been left disconnected from the terminals at the
factory. To connect the battery cables, proceed as follows:
Using the lever on the back of the seat frame, lift up on the
lever and tilt the seat forward.
NOTE:
negative battery terminal is marked Neg. (–).
NOTE: If the positive battery cable is already attached, skip
ahead to step 2.
Remove the plastic cover, if present, from the positive 2.
battery terminal and attach the red cable to the positive
Remove the plastic cover, if present, from the negative
battery terminal and attach the black cable to the negative
4.
terminal to help protect it from corrosion.
NOTE: If the battery is put into service after the date shown
on top/side of battery, charge the battery as instructed in the
the tractor.
Figure 3-10
