23Section 6 — Maintenance & adjuStMentS
Smart Jet (If equipped)
Your tractor’s deck is equipped with a water port on its surface as
part of its deck wash system.
Use the Smart Jet to rinse grass clippings from the deck’s
underside and prevent the buildup of corrosive chemicals.
Complete the following steps AFTER EACH MOWING:
1. Drive the tractor to a level, clear spot on your lawn, near
enough for your garden hose to reach.
CAUTION: Make certain the tractor’s discharge
chute is directed AWAY from your house, garage,
parked cars, etc.
2. Disengage the PTO, set the parking brake and stop the
engine.
3. Thread the hose coupler (packaged with your tractor’s
Operator’s Manual) onto the end of your garden hose.
4. Attach the hose coupler to the water port on your decks
surface. See Figure 6-2.
Figure 6-2
5. Turn the water on.
6. While sitting in the operator’s position on the tractor, start
the engine and place the throttle/choke control lever in the
FAST position.
7. Move the tractor’s PTO into the engaged (ON) position.
8. Remain in the operator’s position with the cutting deck
engaged for a minimum of two minutes, allowing the
underside of the cutting deck to thoroughly rinse.
9. Move the tractor’s PTO into the disengaged (OFF) position.
10. Turn the ignition key to the STOP position to turn the
tractor’s engine off.
11. Turn the water off and detach the hose coupler from the
water port on your deck’s surface.
NOTE: On 50” and 54” decks there are two water ports; one
on each side of the deck.
12. After cleaning your deck with the Smart Jet system, return to
the operator’s position and engage the PTO. Keep the cutting
deck running for a minimum of two minutes, allowing the
underside of the cutting deck to thoroughly dry.
Lubrication
WARNING! Before lubricating, repairing, or
inspecting, always disengage the PTO, set the
parking brake, stop the engine and remove the key
to prevent unintended starting.
Front Wheels
Each of the front wheel axles and rims is equipped with a grease
fitting. See Figure 6-3 for the location of the grease fitting on the
axles and Figure 6-4 for the location of the grease fitting on the
rims. Lubricate with a No. 2 multi-purpose grease applied with a
grease gun after every 25 hours of tractor operation.
Figure 6-3
Figure 6-4
Deck Wheels
The wheels on the deck which are spherical shaped (50” and 54”
decks have 4) are equipped with a grease fitting. Lubricate with a
No. 2 multi-purpose grease applied with a grease gun after every
25 hours of tractor operation.
