Cube AERIUM C:68X - 5 Seatpost;Saddle; Overview; Installing the Seatpost

16
AERIUM C:68X/C:68 TT
5 Seatpost/saddle
5.1 Overview
1
2
3
4
5
1 Seatpost (#57552)
2 Saddle clamp (#33346 [7x7mm] / # 33347
[7x9.6mm])
3 Seat tube seal (#34023)
4 Seatpost clamp (#32323)
5 Aerium C:68 TT seatpost clamp adapter (#3562)
DANGER
Before every ride, check the seatpost
and saddle are correctly installed.
5.2 Installing the seatpost
1
2
3
4
5
Fig. 1: Aerium seatpost installation
Remove the cover (1) on the top tube, in order to
install the magnetic adapter plate (2) in the seat tube
for axing the bolts. Proceed as shown in the detailed
illustration.
Start with the threaded plate (2). Place it into the
recess in the seat tube and then loosely tighten the
bolts (3) from the outside, so that the threaded plate
cannot fall into the seat tube. Now attach the mag‐
netic counterpart (4) - Aerium C:68X or (5) - Aerium
C:68 TT to the threaded plate in the seat tube.
