7 Hydration system
7.1 Installation
1. Remove the stem cover by lifting it up until the
magnetic connection disengages.
Then pull the cover backwards and o.
2.
Attach the magnetic adapter plate to the
basebar using three bolts and tighten to the cor‐
rect torque (max.2.5Nm).
3. Introduce the bottle to the basebar from the
front.
🡆
The magnetic click system pulls the bottle
into the correct position and holds it rmly in
place.
7.2 Removal
1.
To remove the hydration system, press and hold
the button on the right-hand side of the adapter
plate to disengage the retention mechanism.
