Cube Fold Hybrid User Manual

2
Faltmechanismus CUBE Fold Hybrid
1 Operating manual to
the folding mechanism
of the CUBE Fold
Hybrid
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16 17 18 19
20
21
22
23
24
25
26
27
28
29
11
14
15
16
8
12
12
1 Frame
2 Folding joint
3 Carrying handle
4 Saddle
5 Seat post
6 Seat clamp
7 Battery
8 Brake
9 Rear carrier
10 Rear light
11 Mudguard
12 Hub
13 Cassette
14 Rim
15 Tire
16 Spoke
17 Rear Derailleur
18 Chain
19 Kickstand
20 Chain ring
21 Crank arm
22 Mid-drive motor
23 Fork
24 Folding stem
25 Headlight
26 Display
27 Brake lever
28 Shifter
29 Grip
General notes on these operating instructions
NOTICE
The exclamation mark (without tri‐
angle) alerts you to information that
requires special attention.
WARNING
The yellow warning triangle in
combination with the signal word
"Warning" indicates dangers that can
lead to slight personal injury and
damage to property.
DANGER
The yellow warning triangle in combi‐
nation with the signal word "Danger"
indicates dangers that can lead to
severe personal injury (up to death).
General information
This supplementary operating manual is intended to
familiarize you with the correct handling of the folding
mechanism of your Fold Hybrid.
If you should have any further questions about
the correct operating of the folding mechanism
of your Fold Hybrid, please always contact your
CUBE Specialist Dealer.
NOTICE
Always make sure that your Fold
Hybrid stands securely when you
transport it in the folded state.
Especially when transporting in
public transport and in the car, make
sure that the bike is secured against
falling over.
When falling over, your bike can be
damaged.
