Cubic COM5000-8 - Page 15

351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
5
0
31.6
0
23.7
19
28.7
21.9
24
Typical Bolt Hole Pattern
Bolt-down brackets
can be rotated 360°
Pivot radius = 2.75
Slot size = 1.2 x 0.4
All dimensions
are in inches
Figure 2.1.4.2A. Rack Cabinet Mounting Hole Locations
