Cubic COM5000-8 - 3.3 Transmitter System Operation Modes

351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
6
83.1” (211cm)
23.7” (60.2cm)
Figure 2.1.4.2B. Rack Cabinet Module Location
Power Supply
Module
(7U)
1.25 kW PA Module
#4
(6U)
T-4180 Exciter
Module (3U)
System Controller
Module (3U)
4-Way Combiner
Module (3U)
Blank Panel
(2U)
1.25 kW PA Module
#3
(6U)
1.25 kW PA Module
#2
(6U)
1.25 kW PA Module
#1
(6U)
2.25” (5.7cm)
Lifting Eyes (4X)
