COM5000-8 TECHNICAL MANUAL
20
PA Module Fault Decoding Tables
Left Digit (P)
350W AMP 2B
350W AMP 2A
350W AMP 1B
350W AMP 1A
0
OK
OK
OK
OK
1
OK
OK
OK
FAULT
2
OK
OK
FAULT
OK
3
OK
OK
FAULT
FAULT
4
OK
FAULT
OK
OK
5
OK
FAULT
OK
FAULT
6
OK
FAULT
FAULT
OK
7
OK
FAULT
FAULT
FAULT
8
FAULT
OK
OK
OK
9
FAULT
OK
OK
FAULT
A
FAULT
OK
FAULT
OK
B
FAULT
OK
FAULT
FAULT
C
FAULT
FAULT
OK
OK
D
FAULT
FAULT
OK
FAULT
E
FAULT
FAULT
FAULT
OK
F
FAULT
FAULT
FAULT
FAULT
Middle Digit (X)
Filter
Temperature
Supply
Critical
0
OK
OK
OK
OK
1
OK
OK
OK
FAULT
2
OK
OK
FAULT
OK
3
OK
OK
FAULT
FAULT
4
OK
FAULT
OK
OK
5
OK
FAULT
OK
FAULT
6
OK
FAULT
FAULT
OK
7
OK
FAULT
FAULT
FAULT
8
FAULT
OK
OK
OK
9
FAULT
OK
OK
FAULT
A
FAULT
OK
FAULT
OK
B
FAULT
OK
FAULT
FAULT
C
FAULT
FAULT
OK
OK
D
FAULT
FAULT
OK
FAULT
E
FAULT
FAULT
FAULT
OK
F
FAULT
FAULT
FAULT
FAULT
Right Digit (A)
VSWR
Driver
Fan
NA
0
OK
OK
OK
Not used
1
OK
OK
OK
Not used
2
OK
OK
FAULT
Not used
3
OK
OK
FAULT
Not used
4
OK
FAULT
OK
Not used
5
OK
FAULT
OK
Not used
6
OK
FAULT
FAULT
Not used
7
OK
FAULT
FAULT
Not used
8
FAULT
OK
OK
Not used
9
FAULT
OK
OK
Not used
A
FAULT
OK
FAULT
Not used
B
FAULT
OK
FAULT
Not used
C
FAULT
FAULT
OK
Not used
D
FAULT
FAULT
OK
Not used
E
FAULT
FAULT
FAULT
Not used
F
FAULT
FAULT
FAULT
Not used
