ASSEMBLY INSTRUCTIONS
STEP 4
-----------------------------------------------------------------------------------
Attach the Left Rear Leg (19) and the Right Rear Leg (21) to the Cart Shelf using the same procedure as •
Step 3. Then attach the upper section of both legs to the respective cart brackets using 4x Lock
Screw (C).
STEP 5
-----------------------------------------------------------------------------------
Assemble the Rear Cart Bracket (28) to the existing assembly using 4x Lock Screw (C).•
