9
01040707 B 07/21
Culligan Smart HE Iron-Cleer Filters
10" Iron-Cleer 12" Iron-Cleer
Control Valve Type
1” Reinforced Thermoplastic w/GBX
Circuit Board
1” Reinforced Thermoplastic w/GBX
Circuit Board
Installation Environment Indoor Indoor
Overall Conditioner Height 67" 65"
Media Tank Dimensions (D x H) 2 ea� 10" x 54" 2 ea� 12" x 52"
Filter Media Type 1�0 cu� ft Birm 1�5 cu� ft Birm
Underbedding
G-50 35 lb 35 lb
Cullsan U 25 lb 25 lb
Capacity
1
1400 gallons 2000 gallons
Freeboard
2
21" 18"
Max� Clear Water (Soluble) Iron 10 ppm 10 ppm
Max� Hydrogen Sulfide
3
5�0 ppm 5�0 ppm
Minimum Alkalinity 100 ppm 100 ppm
pH for Iron Removal 7�0 - 8�5 7�0 - 8�5
Service Flow @ Pressure Drop (Clean Bed)
Normal 4 gpm @ 6 psi 4 gpm @ 4 psi
Maximum
4
6 gpm @ 9 psi 9 gpm @ 14 psi
Operating Pressure 20-60 psi 20-60 psi
Operating Temperature 33-120° F (1-48° C) 33-120° F (1-48° C)
Electrical Requirements (Control Valve) 24VDC, 1W/60 Hz 24VDC, 1W/60 Hz
Electrical Requirements (Compressor)
120VAC/60Hz, 175W/245W
(continuous/max)*
120 Volts/60Hz, 175W/245W
(continuous/max)*
Drain Flow, Maximum 10 gpm (5�5 gpm minimum required)
10 gpm (8�0 gpm minimum
required)
Regeneration Time
Backwash 5–20 minutes 5–20 minutes
Fast Rinse 5–20 minutes 5–20 minutes
1
Capacity based on 4 gpm and 10 mg/L of dissolved iron�
2
Measure from top of media bed to top of inlet fitting�
3
Hydrogen sulfide will be reduced significantly in water containing less than 5 ppm as tested by Culligan�
4
Max flow rates and pressure drop characteristics have not been validated by the Water Quality Association or IAPMO R&T�
The maximum specified flow rate at which the system will deliver treated water is defined as service flow�
* When compressor is running periodically, otherwise the power consumption is ~1 watt�
