Culligan Aquasential Cullar - System Specifications; Smart HE General & Filtr-Cleer Specs

8
01040707 B 07/21
Culligan Aquasential Smart High Efficiency (HE) Water Filters
Culligan Smart HE Filters
9"
9” Outdoor
10"
10” Outdoor
General
Control Valve type
1” Reinforced Thermoplastic w/GBX
Circuit Board
1” Reinforced Thermoplastic w/GBX
Circuit Board
Installation Environment Indoor / Outdoor Indoor / Outdoor
Filter Tank Size 9 x 48 in� (229x1,219mm) 10 x 54 in� (254x1,372mm)
Temperature Limits 33-120°F (1-50°C) 33-120°F (1-50°C)
Water Pressure Limits 20-120 psi (140-830kPa) 20-120 psi (140-830kPa)
Water Pressure Limits (Canada) 20-90 psi (140-620kPa) 20-90 psi (140-620kPa)
Electrical Requirements (Control Valve) 24VDC, 1W/21�6 Watts 24VDC, 1W/21�6 Watts
Overall Height 54 in� (1,372 mm) 60 in� (1,524 mm)
Filtr-Cleer
®
Rated Service Flow @ Pressure Drop 7�6 gpm @ 15 psi 8�1 gpm @ 15 psi
Minimum Practical Filtration Size 15 microns 15 microns
Maximum Particulate Matter 150 NTU 150 NTU
Maximum Suspended Solids 150 mg/L 150 mg/L
Drain Flow, Maximum
1
4�5 gpm 7�0 gpm
pH Limitation 6�0 - 9�5 6�0 - 9�5
Recharge Time
2
21 min� 21 min�
Recharge Water Consumption, Av�
3
90 gal� 140 gal�
Freeboard
4
20 ± 1�5 inches 19 ± 1�5 inches
Cullar
®
Rated Service Flow @ Pressure Drop 4�0 gpm @ 2�0 psi 5�9 gpm @ 5�0 psi
Drain Flow, Maximum
1
3�5 gpm 5�5 gpm
pH Limitation 5�0 - 11�0 5�0 - 11�0
Recharge Time
2
21 min� 21 min�
Recharge Water Consumption, Av�
3
40 gal� 110 gal�
Cullar Media Volume 0�73 cu� ft 1�5 cu� ft
Cullsan
®
Underbedding Media Amount 10 lb (�1 ft
3
) 20 lb (�2 ft
3
)
Freeboard
4
22 ± 1�5 inches 24 ± 1�5 inches
Rated Capacity 120,000 gallons 180,000 gallons
Cullneu
®
Rated Service Flow @ Pressure Drop 4�0 gpm @ 2�0 psi 5�9 gpm @ 3�0 psi
Drain Flow, Maximum
1
3�5 gpm 5�5 gpm
pH Limitation* 5�2 to 6�8 5�2 to 6�8
Recharge Time
2
21 min� 21 min�
Recharge Water Consumption, Av�
3
70 gal� 110 gal�
Cullneu Media Volume
5
1�0 cu� ft 1�5 cu� ft
Freeboard
4
13 ± 1�5 inches 18 ± 1�5 inches
1
Backwash at 120 psi (830 kPa)�
2
Factory settings�
3
Factory settings and 120 psi line pressure�
4
Measured from top of media to top surface of tank threads� (backwashed and drained)�

NOTE! Filtr-Cleer media is pre-measured, boxed, and
shipped with each Filtr-Cleer system.
Specifications
