Culligan High Efficiency 1.5 Twin Series User Manual

Installation 7
Cat. No. 01024821
Mount the Control Valve
Figure 3. Mounting the control valve.
1. Lubricate the outlet distributor O-ring
with a silicone-based lubricant.
2. Install the inlet disperser to the
bottom of the control valve.
3. Install the tank adapter o-ring
above the valve’s threads. Do
not lubricate, but can be wetted
with water.
4. Lower the control valve slowly onto
the tank so that the distributor tube fits
into the center of the control valve and
then screw the control onto the tank.

Culligan High Efficiency 1.5 Twin Series Specifications

General

Brand	Culligan
Model	High Efficiency 1.5 Twin Series
Category	Water Dispenser
Language	English
