Culligan High Efficiency 1.5 Twin Series User Manual

62 Culligan® High Efficiency 1.5 Twin Water Softener
62 Cat. No. 01024821
24"x50" Brine System
1
3
2
5
4
6
7
8
Figure 64. 24”x50” brine system.
Item No. Part No. Description Qty
— 01024638
24"x50" Brine System Complete, 0.8 gpm, 1/2" Connection, 0.8 BLFC (includes
items 1 - 8)
— 01024666 Tank, Brine, 24x50, w/Well & Cover (includes items 1- 7)
1 — Tank 1
2 — Cover 1
3 01019623 Salt Plate, 24" 1
4 01019621 Brine Well 1
5 01019622 Brine Well Cap 1
6 — Bushing, 3/4" x 1" NPT 1
7 — Elbow, 1" NPT x 1" Socket 1
8 01024634 Brine Valve, 1/2" Connection, 0.8 gpm, BLFC 1
