Accessories 43
Cat. No. 01023095
2) LANGUAGE
3) POWERON MODE
4) FLUSH MODES
>5) ACCESSORIES
4. Press to select 5)ACCESSORIES. The screen displays the ac-
cessories menu.
1) WIRELESS REM
2) MODEM
3) FLOW METERS
>4) SWITCH INPTS
5. Press to select 4)SWITCH INPTS. The screen displays the switch
inputs settings.
Switch Inputs Settings
Screen Display Range Changing the Setting
PRESSURE SWITCH
NORMALLY OPEN
Normally Open
Normally Closed
Used with the inlet pressure switch. Standard pressure switch is
normally open. Press
or and then to change the
state if necessary.
PS Sw
Delay: 5
SECONDS
0–9,#
each digit
Sets the pressure switch delay time. This is the number of seconds
the low pressure must exist before activating the switch. Press
or and then to change.
SV1 Delay:
10
SECONDS
0–300
The number of seconds elapsed from the inlet solenoid valve (SV-
1) opening until the motor starts. Press
or and then
to change.
PRETREAT SWITCH
NORMALLY OPEN
Normally Open
Normally Closed
Used with the inlet pressure switch. Standard pressure switch is
normally open. Press
or and then to change the
state if necessary.
FLOAT SWITCHES
NORMALLY OPEN
Normally Open
Normally Closed
Used to set whether float switches (level control) are normally
open or closed. There are two float switch contacts; they both must
be normally open or closed. Press
or and then to
change the state if necessary.
FS Hi
Delay: 0
MINUTES
0–120
Used only when only one float switch (high) contact exists. This
sets how long the float switch stays closed after transitioning from
high to low level.
RUNNING
JAN-01-12 12:01P
6. Press to save the settings and return to the home screen.
Pressure Transducers (Pressure Gauges)
They are not used for M2 RO units
