Culligan Soft-Minder 2005 - Specifications; Twin Specifications

Specifications
4 Culligan Platinum Plus
®
Series
Twin Specifications
SM-61 Model SM-91 Model
Control Valve Reinforced Thermoplastic Reinforced Thermoplastic
Overall Conditioner Height
Media Tank Design Quadra-Hull or FRP Quadra-Hull or FRP
Media Tank Dimensions (Dia x Ht) 9 x 48 in 10 x 54 in
Salt Storage Tank Dimensions (Dia x Ht) 16 x 43 in 18 x 43 in
18 x 43 in
Exchange Media, Type and Quantity Cullex
®
Media, 1.0 ft
3
Cullex
®
Media, 1.5 ft
3
Underbedding, Type and Quantity Cullsan
®
Underbedding, 12 lb
Cullsan
®
Underbedding, 15 lb
Exchange Capacity 13,760 gr @ 3.3 lb 21,193 gr @ 5 lb
@ Salt Dosage Per Recharge 27,848 gr @ 9.3 lb 42,890 gr @ 14 lb
32,939 gr @ 15 lb 50,732 gr @ 22.5 lb
Efciency rated dosage
1
4130 gr/lb @ 3.3 lb salt dosage 4,240 gr/lb @ 5 lb salt dosage
Freeboard to Media
2
14.5 in 14.5 in
Freeboard to Underbedding
3
44.5 in 47.5 in
Salt Storage Capacity 250 lb or 375 lb 375 lb
Rated Service Flow @ Pressure Drop 10.7 gpm @ 15 psi 10.2 gpm @ 15 psi
Total Hardness, Maximum 75 gpg 99 gpg
Total Iron, Maximum 5 ppm 5 ppm
Hardness to Iron Ratio, Minimum 8 gpg to 1 ppm 8 gpg to 1 ppm
Operating Pressure 20-125 psi 20-125 psi
Operating Temperature 33-120°F 33-120°F
Electrical Requirements 24V/60 Hz 24V/60 Hz
Electrical Power Consumption, Min/Max 5 Watts/ 6 Watts 5 Watts/ 6 Watts
Drain Flow, Maximum
4
2 gpm 2 gpm
Recharge Time, Average
5
67 min 67 min
Recharge Water Consumption, Average
5
57 gal 57 gal
1 The efciency rated dosage is only valid at the stated salt dosage and is efciency rated according to NSF/ANSI 44.
2 Measured from top of media to top surface of tank threads. (backwashed and drained).
3 Measured from top of underbedding to top surface of tank threads.
4 Backwash at 120 psi (830 kPa).
5 10 minute backwash, 3.3 lb 9” model, 5 lb (2.7kg) 10” model.
