Remove
Remove the piston cooling nozzles. Refer to Procedure
001-046 in Section 1.
(/qs3/pubsys2/xml/en/procedures/133/133-001-046-tr-
mixab.html)
Remove the cylinder head. Refer to Procedure 002-004 in
Section 2. (/qs3/pubsys2/xml/en/procedures/133/133-
002-004-tr-mixab.html)
Remove the lubricating oil pump (required for cylinder 6
access only). Refer to Procedure 007-031 in Section 7.
(/qs3/pubsys2/xml/en/procedures/133/133-007-031-tr-
mixab.html)
WARNING
When using solvents, acids, or alkaline materials for cleaning,
follow the manufacturer's recommendations for use. Wear
goggles and protective clothing to reduce the possibility of
personal injury.
WARNING
Some solvents are flammable and toxic. Read the
manufacturer's instructions before using.
CAUTION
Do not use emery cloth or sandpaper to remove carbon from
the cylinder liners. Aluminum oxide or silicon particles from
emery cloth or sandpaper can cause serious engine damage.
Do not use any abrasives in the ring travel area. The cylinder
liner can be damaged.
Use a fine, fibrous, abrasive pad such as Scotch-Brite™ 7448,
Part Number 3823258, or equivalent, and solvent to remove
carbon from the cylinder liners as needed.
