No. Consumers/Amps
32
Control unit for park dis-
tance control, front camera
and radar
7.5/10
33 Airbag 7.5
34
Reverse switch, climate sen-
sor, electrochromic mirror,
rear power sockets (USB)
7.5
35
Diagnosis, headlight control
unit, headlight adjuster
7.5
38 Trailer 25
39 Right door 30
40 12V socket 20
41
Driver and passenger seat
belt pre-tensioner
25
42 Central locking 40
43 Beats Audio CAN and MOST. 40
44 Trailer 15
45 Electric driver's seat 15
46 USB socket 7.5
47 Rear window wiper 15
49 Starter motor; clutch sensor 7.5
52 Driving mode 15
53 Heated rear window 30
In-line fuse/Amps
230V rear power sockets 30
Fuse arrangement in engine compartment
No. Consumers/Amps
1 ESP control unit 25
2 ESP control unit 40/60
3 Engine control unit 15
4 Engine sensors 10
5 Engine sensors 10
6 Brake light sensor 7.5
7 Engine power supply 10
8 Lambda probe 10
10
Pump control unit for T3W
Cupra
30
11 PTC 40
12 PTC 40
13 Gearbox pump 30
14 Heated windscreen 50
15 Horn 15
16 Petrol pump 20
17 Engine control unit 7.5
18
Terminal 30 (positive refer-
ence)
7.5
No. Consumers/Amps
19 Front windscreen washer 30
21
Automatic gearbox control
unit
15
22 Engine control unit 7.5
23 Starter motor 30
24 PTC 40
36 Left LED headlight 15
37 Parking heating 20
38 Right LED headlight 15
Note
●
In the vehicle, there are more fuses than
those indicated in this chapter. These should
only be changed by a specialised workshop.
●
Positions not containing a fuse do not ap-
pear in the following tables.
●
Some of the equipment listed in the tables
below pertain only to certain versions of the
model or are optional extras.
●
Please note that the above lists, while cor-
rect at the time of printing, are subject to
change.
