WIRING: STANDARD INSTALLATION, 1212
e wiring diagram presented in Figure 3a shows a typical installation for a DME application. is
installation is shown with a single-ended 3-wire 5kΩ potentiometer throttle and a reverse switch.
With wigwag throttles, a reverse switch is not used and Pin J1-12 is le unconnected.
e optional speed inhibit input can be wired into the circuit in various ways; in the standard
installation shown here, it is B- active (Inhibit Type parameter set to 0).
e J2 connector can be used interchangeably for the programmer or for the battery charger.
Figure 3a
Standard Wiring Configuration, Curtis 1212 Controller.
