Curtis Instruments 1212 User Manual

3 — PROGRAMMABLE PARAMETERS
pg. 19
Return to TOC 1212 & 1212P Manual - Sep 2019
THROTTLE MENU, cont’d
PARAMETER ALLOWABLE RANGE DESCRIPTION
Speed Limit Pot On/Off This parameter is used to enable/disable the speed limit pot. If no speed limit
pot is used, set Speed Limit Pot to Off.
Throttle Map 20–80 % The throttle map parameter adjusts the static throttle map. The parameter
setting corresponds to the throttle command at half throttle, as shown in
Figure 7.
A setting of 50% provides linear response. Values below 50% reduce the
throttle command at low throttle positions, providing enhanced slow speed
maneuverability. Values above 50% give the vehicle a faster, more responsive
feel at low throttle positions.
Tremor Suppression 0–100 % This parameter can be used to limit the controller’s response to sharp throttle
movements, such as movements resulting from hand tremors.
Larger values will provide a steadier ride, but they also result in more sluggish
response to throttle request. There is thus a trade-off between crispness of
response (low Tremor Suppression settings) and steady speed in the presence
of tremors (high settings).
Figure 7
Eect of rottle Adjustment
Parameters. ese Four
Parameters Determine e
Controller’s Response to
rottle Position, in Forward
and Reverse.
Here,
Deadband = 10%
rottle Max = 90%
Creep = 0%.
