Curtis 906 - MODEL ENCODEMENT; Model Encodement - Case Style Options; Model Encodement - Voltage Options

2
Example: Model 906 D 24 M C D A O
Case Style
Voltage
Reset
Discharge
Output
Special
Options
1 3 5
2 4 6
Artwork
7
Case Style Options
1
12
24
36
48
Voltage
Options
2
1. MODEL ENCODEMENT
D DIN case – rectangular
F Hex bezel w/1/4” spade terminals (enGage I)
J Hex bezel w/Packard connector (enGage I)
N DIN case - rectangular, snap-fit
P Pin mount (module)
R 52mm Round bezel & case (same as 700Q)
T Hex bezel w/3/16” spade terminals (enGage I)
TX Hex bezel w/3/16” spade terminals (old T case)
Y Rectangular bezel w/Packard connector (enGage I)
Z Rectangular bezel w/1/4” spade terminals (enGage I)
