7
Recommended Panel Cutouts
F, J, T, TX, Y, Z Cases: 36.8 mm x 24.1 mm
+0.3/-.0mm
D, N Cases: 45.3 mm x 22.3 mm ±0.1
R Case: 52.4 mm
Terminals
D, N, T, TX: 3/16” blade
R, F, Z: 1/4” blade
J, Y: 4-pin Packard Connector equivilent to
Delphi PN 15336035
P: Solder pins
2.3 Environmental Temperature
Operating: –40 to +85°C
Storage: –50 to +90°C
Humidity: 95% RH non-condensing at 38°C
Shock and Vibration: Meets SAE J 1378
