Curtis CAFE0AP10A000 User Manual

ILLUSTRATED PARTS LIST IP65
CAFE GLASS DECANTER BREWER, ILLUSTRATED PARTS/RECOMMENDED PARTS 102617NC
ITEM # PART # DESCRIPTION
1 WC-54121 PAN, POUR CAFÉ
2A WC-207
1,3
LIGHT, BREW 115V GREEN
2B WC-208
2,4
LIGHT, BREW 250V GREEN
3 WC-3502 LEG, 8-32 STUD SCREW BUMPER
4 WC-3645
SPRING, DELIMING .041 X 20”
GALVANIZED WIRE HARD DRAWN
5 WC-54118 TRAY, ASSY CAFE POUR OVER
6 WC-4213 NUT, 5/8 LOCK PLATED
7A WC-735-101
1,3
THERMOSTAT, TEMPERATURE
CONTROL 120VAC POUROVER CAFE
7B WC-504
2,4
THERMOSTAT, CAPILLARY SPST 250V
25A GEM
8 WC-39371 LABEL, SW PANEL CAFÉ AP CURTIS
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
ITEM # PART # DESCRIPTION
10 WC-29054 TUBE, W/A CAFE POUR OVERS
11 WC-3621-101
BREW CONE, NON-METAL UNIVERSAL
(WITH SPLASH POCKET)
12A WC-13301-101
1,3
HARNESS ASSY, CAFE AP 120V FOR
ELECTRONIC THERMOSTAT
12B WC-13301
2,4
HARNESS ASSY, CAFÉ AP 220V
13 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
14 WC-1408 CORD GRIP, 7/8” O.D.
15A WC-1200
1,3
CORD, 14/3 SJTO 6’ BLK W/PLUG
15B WC-1231-103
2,4
CORD, 2.5 mm² PRE-CUT W/
CONNECTORS
16 WC-103
2,4
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
17 WC-5231 COMPOUND, SILICONE 5 OZ
CAFE0AP, CAFE0PP - Main Chassis - Parts List
1
CAFE0AP10A000,
2
CAFE0AP30A000,
3
CAFE0PP10A000,
4
CAFE0PP30A000
ITEM # PART # DESCRIPTION
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
13 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
16 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
ITEM # PART # DESCRIPTION
17 WC-5231 COMPOUND, SILICONE 5 OZ
CAFE0AP, CAFE0PP - Main Chassis - Recommended Parts to Stock

Curtis CAFE0AP10A000 Specifications

General

Brand	Curtis
Model	CAFE0AP10A000
Category	Coffee Maker
Language	English
