Curtis G4TP2S10A3500 - Page 17

ROUGH-IN DRAWINGS RD30
G4TP2T - Twin Coffee Brewer
G4TP2S - Single Coffee Brewer
G4TP2, ROUGH-IN DRAWING 041217A
20.75 in
[52.7 cm]
20.75 in
[52.7 cm]
24.00 in
[60.0 cm]
24.00 in
[60.0 cm]
8.38 in
[21.0 cm]
8.38 in
[21.0 cm]
35.14 in
[89.2 cm]
35.42 in
[90.0 cm]
4.00 in
[10.2 cm]
4.00 in
[10.2 cm]
11.07 in
[28.1 cm]
20.07 in
[51.0 cm]
