Curtis G4TP2S10A3500 User Manual

ELECTRICAL SCHEMATICS ES52
GTPTG4-30, ELECTRICAL SCHEMATIC 053117A
1
230V a c Hot Input
1
12 Vac Input
2
230V a c Hot Input
2
12 Vac Input
3
Brew Valve Right
3
Ta n k Water Le v e l Probe
4
Brew Valve Le ft
4
Vdd +5V d c
5
230V a c L2
5
Not Used
Not Used
6
Inlet Valve
6
Ta n k Tem p e rature Se n so r
7
Not Used
7
Ta n k Tem p e rature Se n so r
8
Not Used
8
(Data_C om m unication Next)
Not Used
9
Triac Gate
9
Vss- (Lo g ic_C om m on)
10
Triac A2
10
So l
id Sta te Relay +5V d c
11
Brew Cone Lock Right
11
Data_Com m unication First
12
Brew Cone Lock Le ft
12
13
Warmer Right
13
So lid Sta te Relay - Com m on
14
Warmer Le ft
14
Ta n k Ground
15
Byp a ss Valve Right
16
Byp a ss
Valve Le ft
17
Not Used
18
Not Used
19
Current Se n so r
20
Current Se n so r
1
12 Vac Input (B a c k Light)
1
TX - Transm it
2
Vdd +5V d c
2
RX - Receive
3
Vss- (Lo g ic_C om m on)
3
Not Used
4
Not Used
4
Vdd +5V d c
5
12 Vac Input (B a c k Light)
5
Vss- (Lo g ic_C om m on)
6
Data_Com m unication First
7
Not Used
8
Not Used
1
Vss- (Lo g ic_C om m on)
2
TX - Transm it
3
Vdd +5V d c
4
RX - Receive
5
Not Used
6
Not Used
(U C M ) Pin A ssignm ents
USB Pin Assignm ents
6-Pin Connector
(U P M ) Pin A ssignm ents
rotcennoC niP 41rotcennoC niP 02
rotce
nnoC niP 5rotcennoC niP 8
G4TP1T30A3100, G4TP2T30A3100
