Curtis GEM-12D - Satellites & Warmer Stands

18
PARTS
DIAGRAMS
GEM-3, SATELLITE COFFEE SERVER
GEM-5, SATELLITE WARMER
GEM-8, SATELLITE WARMER SHORT
4
2
1
3
6
5
8
7
9
10
11
12
14
15
13
1
1A
2
3
4
5
6
7
7A
8
9
10
11
12
13
14
15
WC-5622
WC-3307
WC-2102
WC-2005*
WC-2010C
WC-2025*
WC-2006*
WC-1800
WC-1841
WC-3705*
WC-1901A
WC-37102
WC-3503
WC- 114R
GEM-3
GEM-5
GEM-8
LID, SATELLITE PLASTIC GEM3
LID, SATELLITE STAINLESS (OLDER UNITS)
GAUGE GLASS ASSEMBLY 8”
WASHER, SHIELD CAP 1/8”
SHIELD, 8 INCH GAUGE GLASS
GAUGE GLASS, 8 INCH
WASHER, SHIELD BASE 3/16”
FAUCET, S’ NON LOCKING
FAUCET, ESP BLACK NON-LOCKING PLASTIC
KIT, FAUCET S’ SERIES
SHANK, FAUCET W/SHIELD BASE
KIT, WARMER ELEMENT 100W 120V
LEG, SCREW BUMPER 3/8”– 16 STD
SWITCH, ROCKER (RED) 120V NEON SPST 15A 250V
SATELLITE SERVER 1/2 GALLON
SATELLITE WARMER STAND 120V 100W 1A 1PH 2W+G
SATELLITE WARMER STAND, SHORT 120V 100W
Nº Part Nº Description
* Suggested parts to stock for servicing.
