Curtis GEMTIF - Rough-In Drawings and Dimensions; GEMTIF Installation Dimensions; GEMSIF Installation Dimensions; GEM3 IF Installation Dimensions

16
SHOWING WC-37259
BREW CONE ASSEMBLY
.125”
(.3 cm)
.25”
(.6 cm)
1.0”
(2.5 cm)
30.5”
(77.5 cm)
4.0”
(10.0 cm)
5.375”
(13.7 cm)
7.75”
(19.7 cm)
11.75
(29.8 cm)
11.25”
(28.6 cm)
18.125”
(46.1 cm)
22.125”
(56.2 cm)
12.0”
(30.5 cm)
11.75”
(29.8 cm)
.75”
(1.9 cm)
7.75”
(19.7 cm)
4.0”
(10.2 cm)
5.625”
(14.3 cm)
30.5”
(77.5 cm)
11.625
(29.5 cm)
11.875”
(30.2 cm)
9.125”
(23.2 cm)
22.125”
(56.2 cm)
13.25”
(33.7 cm)
9.0”
(22.9 cm)
11.5”
(29.2 cm)
10.25”
(26.0 cm)
10.0”
(25.4 cm)
11.75”
(29.8 cm)
9.0”
(22.9 cm)
GEMTIF
GEM3IF
GEMSIF
Rough-In Drawings
