Curtis TLP12A User Manual

ILLUSTRATED PARTS LIST IP62
TLP, ILLUSTRATED PARTS/RECOMMENDED PARTS 011618B
ITEM # PART # DESCRIPTION
1 WC-8591 CAPACITOR, X2 USED ON ALL ADS MODELS
2 WC-1040 PUMP, WATER CENTRIFUGAL 120V 60HZ TLP
3A WC-61336
1
COVER, TOP TLP
3B WC-61355
2,3
COVER, TOP SS TLP
4A WC-2962K
a
KIT, FITTING SPRAYHEAD SS
4B WC-2962-101K
b
KIT, FITTING SPRAYHEAD KYNAR
5 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
6 WC-715 CONTROL MODULE, UPM 120Vac TLP
7 WC-717
CONTROL BOARD, SMART CARD SWITCH
ASSY COMPLETE TLP
8 WC-39662 LABEL, CONTROL PANEL TLP CURTIS LOGO
9 WC-29030
SPRAYHEAD, ASSY ADVANCED FLOW
ORANGE,USE W/PUMP MODELS ONLY
10 WC-66050 DRIP, TRAY TLP
11A WC-3316
BREW CONE, W/HANDLE ASSY 7.1”D.W/WC-
3317 & WC-3323 ALP/AP
11B WC-3621-101
BREW CONE, NON-METAL UNIVERSAL (WITH
SPLASH POCKET)
12A WC-61335
1
COVER, SIDE TLP
12B WC-61354
2
COVER, SIDE SS TLP
12C WC-61354-101
3
COVER, SIDE SS TLP 19”
ITEM # PART # DESCRIPTION
13 WC-2401K KIT, ELBOW 3/8 NPT X 1/4 FLARE
14 WC-1408 CORD GRIP, 7/8” O.D.
15 WC-1200 CORD, 14/3 SJTO 6’ BLK W/PLUG
16 WC-13418 HARNESS ASSY, CONTROL 120V TLP
17 WC-29044-101 SLEEVE, OVERFLOW
18A WC-4213
a
NUT, 5/8 LOCK PLATED
18B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
19 WC-826L VALVE, INLET 1 GPM 120V 9W
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, HEAT SINK 5OZ
22 WC-102
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
23 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
24 WC-37252
KIT, HOT WATER FAUCET REPLACEMENT
ALPGT/D60GT/D500GT
25A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
25B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
TLP Series - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
1 WC-8591 CAPACITOR, X2 USED ON ALL ADS MODELS
9 WC-29030
SPRAYHEAD, ASSY ADVANCED FLOW
ORANGE,USE W/PUMP MODELS ONLY
19 WC-826L VALVE, INLET 1 GPM 120V 9W
ITEM # PART # DESCRIPTION
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, SILICONE 5 OZ
22 WC-102
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
TLP Series - Recommended Parts to Stock
1
TLP,
2
TLP12A,
3
TLP12A19
a
1HZHUXQLWV6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Older units.
