Cushman 622015 - Shuttle 2 Detailed Specifications

2 - 3
GENERAL SPECIFICATIONS
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
2
MODEL: SHUTTLE™ 2
TYPE: GASOLINE POWERED CARGO CARRIER
MODEL YEAR: 2012
Part No:. 618849
Engine: 13 hp (9.7 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
z Valve Train: Ov erhead v alv e z Fuel System: Fix ed float bowl with remote pulse fuel pump
z Lubrication: Pressurized oil system, spin-on oil filter z Ignition: Electronic spark/magneto
z Balancer: Internal counter
rotating balance shaft z Air Cleaner: Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 C C A, 60 minute reserve)
Drive T rain: Automatic, continuously variable transmission (CVT)
Brakes: Dual rear w heel mechanical self-adjusting drum brakes.Single point park brake release w ith self-compensating sy stem
T ransaxle: Differential with helical gears
, ground speed gov ernor, forw ard/rev erse
Performance
Ov erall Length 138.5 in (352.0 cm) Seating C apacity 2 Persons
Ov erall Width 46.5 in (118.0 cm) Dry Weight 851 lb (385 kg)
Ov erall Height (No C anopy) 48.6 in (123.0 cm) (Top of steering w heel) Curb Weight 891 lb (405 kg)
Ov erall Height (With Canopy ) 74.0 in (188.0 cm) Vehicle load capacity 1200 lb (545 kg)
Wheel Base 93.5 in (237.0 cm) Outside C learance Circle 25.5 ft (7
.8 m)
Front Wheel Track 34.2 in (89.0 cm) Intersecting Aisle C learance N/A
Rear Wheel Track 38.0 in (97.0 cm) Speed (Lev el Ground) 14 mph ± 0.5 mph (23 kph ± 0.8 kph)
Gnd C learance @ Differential 4.75 in (12.0 cm) Tow ing C apacity N/A
Cargo Bed Width 44.0 in (112.0 cm) Steering & Suspension
Cargo Bed Length 68.5 in (174.0 cm) Steering Self-compensating rack and pinion
Vehicle Power Front Suspension Leaf springs with hydr
aulic shock absorbers
Power Source 4 Cycle 24.5 cu in (401 cc). Low Emission Rear Suspension Leaf springs with hydraulic shock absorbers
Valv e Train Single Cy linder OHV Serv ice Brake Rear w heel mechanical self-adjusting drum
Horsepower (kW) 13 hp (9.7 kW) Exceeds SAE J1940 Std. Parking Brake Self-compensating, single point engagement
Electrical System Starter/Generator. Solid State Regulator Front Tires Links 18
x 8.50 - 8 (4 Ply Rated)
Battery (Qty, Ty pe) One, 12 Volt Maintenance Free Rear Tires Links 18 x 8.50 - 8 (4 Ply Rated)
Key or Pedal Start Pedal Body & Chassis
Air C leaner Industrial Rated Dry Filter Frame Welded steel. DuraShield™ pow der coat
Lubrication Pressurized Oil Sy stem Front Body & Finish Injection molded TPO
Oil Filter Spin-On Rear Body & Finish Steel. Base coat/clear coat
Cooling Sy stem Air C ooled Standard C
olor Champagne
Fuel C apacity 5.3 Gallons (20.0 L) early production tank
Driv e Train Continuously v ariable transmission (C VT)
Transaxle Differential w ith helical gears
Gear Selection Forward - Reverse
Rear Ax le Ratio 11.42:1 (Forw ard) 15.78:1 (Rev erse)
Some items shown may be optional equipment
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW
Dimensions
Specications are subject to change without notice
* Field installed accessories may require installation charges
Noise & Vibration
Sound pressure; continued A-weighted equal to or
less than 76 db(A)
Highest RMS value of weighted acceleration is less than
2.5 m/s
2
Highest RMS value of weighted acceleration is less than
2.5 m/s
2
The uncertainty of measurement is 0.69 m/s
2
Noise
Vibration, WBV
Vibration, HAV
Measurement methods were applied per the ISO 2631 and ISO 5349 standards
under conditions of typical vehicle surfaces.
Fuel C apacity 5.6 Gallons (21.4 L) late production tank
