OPERATING PROCEDURES
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
4 - 4
4
VEHICLE DATA PLATE
The vehicle data plate is located on the inside surface of the canopy strut. The data plate contains information con-
cerning the Date of Manufacture, GVWR, GAWR (Front), GAWR (Rear), Tire and Rim Dimensions, VIN, and Type of
Vehicle.
BEFORE INITIAL USE
Read and follow the safety instructions on the cup holder and header. Understanding how to use this vehicle and its
accessories is essential to safety and good performance. Maintaining good performance depends to a large extent
on the operator.
Hydrogen gas is generated as a natural part of the lead acid battery charging process. A 4%
concentration of hydrogen gas is explosive and could cause severe injury or death. Charging
must take place in an area that is adequately ventilated (minimum of five air exchanges per
hour).
To reduce the chance of battery explosion that could result in severe injury or death, never
smoke around or charge batteries in an area that has open flame or electrical equipment that
could cause an electrical arc.
Before a new vehicle is put into operation, the items shown in the INITIAL SERVICE CHART must be performed.
The vehicle batteries must be fully charged before initial use.
Check for correct tire inflation. See GENERAL SPECIFICATIONS.
Check fluid level in the brake master cylinder.
Check the operation of the brakes.
MFD BY: E-Z-GO DIVISION OF TEXTRON INC.
DATE OF MANUFACTURE: MM/YY
GVWR: XXXX LBS. (XXX KGS)
GAWR (Front): XXX LBS (XXX KGS)
GAWR (Rear): XXXX LBS (XXX KGS)
TIRE & RIM DIMENSIONS:
FRONT 205/50-10 10X7 @ 30PSI (207 KPA)-COLD
REAR 205/50-10 10X7 @ 30PSI (207 KPA)-COLD
THIS VEHICLE CONFORMS TO ALL
APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY STANDARDS IN
EFFECT AT THE DATE OF
MANUFACTURE SHOWN ABOVE
VIN XXXXXXXXXXXXXX
TYPE OF VEHICLE: LSV
Vehicle Data Plate on Header
