MAINTENANCE
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
5 - 12
5
CAPACITIES AND REPLACEMENT PARTS
*If replacing a lost key, the number on
the key must match the number on the
ignition.
FLUID QUANTITY
Rear Axle Lubricant Mobil 424 Gear Oil
25 oz. (740 ml)
Brake Fluid, DOT 3
As Required
Table 1: Capacities
ITEM PART NUMBER
Fuse
ATC 10A (E-Z-GO P/N 35212G07)
Headlight Bulb
894 (E-Z-GO P/N 74004G01)
Front Turn Signal Bulb
2057 (E-Z-GO P/N 604311)
Taillight/ Brake Light Bulb
2057 (E-Z-GO P/N 604311)
*Vehicle Key
E-Z-GO P/N 609680
Table 2: Replacement Parts
ALLTORQUE FIGURES ARE IN FT. LBS. (Nm)
BOLT SI ZE
Grade 2
1/4" 5/16" 3/8" 7/16" 1/2" 9/16" 5/8" 3/4" 7/8" 1"
Unless otherwise noted in text, tighten all hardware in accordance with this chart.
This chart specifies 'lubricated' torque figures. Fasteners that are plated or lubricated when
installed are considered 'wet' and require approximately 80% of the torque required for 'dry' fasteners.
4
(5)
8
(11)
15
(20)
24
(33)
35
(47)
55
(75)
75
(102)
130
(176)
125
(169)
190
(258)
Grade 5
Grade 8
6
(8)
13
(18)
23
(31)
35
(47)
55
(75)
80
(108)
110
(149)
200
(271)
320
(434)
480
(651)
6
(8)
18
(24)
35
(47)
55
(75)
80
(108)
110
(149)
170
(230)
280
(380)
460
(624)
680
(922)
BOLT SI ZE
Class 5.8
(Grade 2)
M4 M5 M6 M8 M10 M12 M14
1
(2)
2
(3)
4
(6)
10
(14)
20
(27)
35
(47)
55
(76.4)
Class 8.8
(Grade 5)
2
(3)
4
(6)
7
(10)
18
(24)
35
(47)
61
(83)
97
(131)
Cla
ss 10.9
(Grade 8)
3
(4)
6
(8)
10
(14)
25
(34)
49
(66)
86
(117)
136
(184)
5.8
8.8
10.9
Torque Specifications and Bolt Grades
