Cushman SHUTTLE 2+2 - Page 20

Page C-3
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BODY
661605 Service Parts Manual
31 71055G01 RIVET (ALUMINUM), 3/16" X 1" LG................................................................ 2
32 613036G0XX COWL (See COLOR CODE in HOW TO USE Section of Manual) ................ 1
33
34 654275 FASCIA BRACKET.......................................................................................... 1
35 01038G01 HEX WASHER HEAD SWAGEFORM SCREW
WITH DOGPOINT, 1/4" - 20 X .7" LG ............................................................. 2
36 16469G1 FENDER WASHER, 9/32"............................................................................... 2
37
38
39
40 75459G03 GLOVE BOX DOOR (PASSENGER SIDE) .................................................... 1
41
42
43 614378 FENDER FLARE (DRIVER SIDE)................................................................... 1
44 613274 FENDER FLARE (PASSENGER SIDE) .......................................................... 1
45 71055G01 RIVET (ALUMINUM), 3/16" X 1" LG................................................................ 3
46
47 654276 FRONT SHIELD BRACE ................................................................................ 2
48
49 664610 COWL STRAP ................................................................................................ 2
