Page D-5
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BRAKES
661605 Service Parts Manual
32 10386G3 CLEVIS PIN, .438" X .938" LG........................................................................ 1
33 10387G3 COTTER PIN, .094" X .75" LG ........................................................................ 1
34
35
36 654663 COMPENSATOR ASSEMBLY (INCLUDES ITEMS 37 - 49) ........................... 1
37 00532G4 HEX NUT, 1/4" - 20 ................................................................................... 2
38 629486 SPHERICAL HEX NUT, 5/16"- 24............................................................. 1
39 28082G01 EQUALIZER BRACKET............................................................................ 1
40 15121G1 FLAT WASHER, 5/16"............................................................................... 2
41 17979G1 ACCELERATOR ROD BUSHING, .464" I.D. X 1" O.D. X 2" LG............... 1
42 23061G2 TUBE......................................................................................................... 1
43 23463G1 COMPRESSION SPRING ........................................................................ 1
44 652256 BRAKE YOKE........................................................................................... 1
45 11098G9 HEX LOCK NUT, 5/16" - 24 ...................................................................... 1
46 612557 COMPENSATOR LINK ROD .................................................................... 1
47 28083G01 BRAKE COMPENSATOR BUMPER......................................................... 2
48 624690 BRAKE CABLE (DRIVER SIDE)............................................................... 1
49 624691 BRAKE CABLE (PASSENGER SIDE) ...................................................... 1
