Cushman SHUTTLE 2+2 - Page 82

Page L-3
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
SEATING
661605 Service Parts Manual
20 617644 HIP RESTRAINT (PASSENGER SIDE).................................................... 1
21 617645 HIP RESTRAINT (DRIVER SIDE) ............................................................ 1
22 645492 BASE ........................................................................................................ 1
23 71012G01 TRIM (POLYPROPYLENE)....................................................................... 1
24 71602GXX VINYL COVER.......................................................................................... 1
71602G01 OYSTER
71602G03 TAN
71602G04 GREY
71602G06 BLACK
71602G07 BROWN
25 71603G02 PADDING (FOAM) .................................................................................... 1
26 71610G01 SEAT HINGE............................................................................................. 2
27
28
29
30 628058GXX FLIP SEAT BOTTOM ASSEMBLY (INCLUDES ITEM 31 - 38) ....................... 1
628058G01 OYSTER
628058G03 TAN
628058G04 GREY
628058G06 BLACK
628058G07 BROWN
31 634190 DECK BOARD ASSEMBLY ...................................................................... 1
32 632837GXX SEAT BOTTOM ASSEMBLY (INCLUDES ITEM 33 - 35) ......................... 1
632837G01 OYSTER
632837G03 TAN
632837G04 GREY
632837G06 BLACK
632837G07 BROWN
33 617400 SEAT BOTTOM (PLYWOOD)............................................................. 1
34 617401 SEAT BOTTOM (FOAM) .................................................................... 1
35 *** SEAT BOTTOM (VINYL) .................................................................... 1
617893 BROWN
615648 BLACK
617892 GREY
615647 TAN
615646 OYSTER
36 16705G1 PHILLIPS SCREW (SS), 1/4" - 20 X 1” LG............................................... 5
37 00559G7 FLAT WASHER, 1/4"................................................................................. 1
38 617402 SEAT STRAP............................................................................................ 1
