Cushman SHUTTLE 2+2 - Page 86

Page L-7
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
SEATING
661605 Service Parts Manual
31 634184 REAR FLIP SEAT HANDRAIL KIT (INCLUDES ITEMS 32 - 37)..................... 1
32 634185 FOOTREST HANDLE WELDMENT ......................................................... 1
33 19859G1 SQUARE TUBE CAP, 3/4""....................................................................... 2
34
35 00427G8 HEX HEAD BOLT, 3/8" - 16 X 2" LG ........................................................ 4
36 614221 FLAT WASHER, 3/8" ................................................................................ 8
37 11098G5 LOCK NUT, 3/8" - 16................................................................................. 4
38
39
40
41 16705G9 TRUSS HEAD PHILLIPS SCREW (SS), 1/4" - 20 X 1.25" LG........................ 4
42 00559G7 FLAT WASHER, 1/4" ....................................................................................... 4
43 14390G4 LOCK NUT, 1/4" - 20 ....................................................................................... 4
