Cutwater 28 - Bilge Pump System

27
BILGE PUMP SYSTEM
The bilge pumps operate automatically with electronic float switches when all switches
and breakers are in the OFF position.
However, the BILGE PUMP and BILGE PUMP2 will run continuously once their switches are placed
in the on position. Monitor the outflow accordingly. Do not run when dry.
12V 750GPH
2
1
High Bilge Alarm
Aft Bilge Pump
Forward Bilge Pump
One Way Check Valve
