STERN COMPONENTS
1 2 3 4 5 7 8 9 10 11 12
6
➊ Brake Lights
➋ Backup Lights
➌ Running Lights
➍ Courtesy Lights
➎ Cockpit Drains
➏ Underwater Lights
➐ Prop Zinc
➑ Stern Thruster
➒ Swim Platform Retractable Ladder
➓ Trim Tabs
Prop
Rudder
11
12
➊ ➊
➍
➋ ➋
➎ ➎
➌ ➌
➏➏
➐
➑
➒
➓ ➓
11
12
➍
