18
AIR CONDITIONING SYSTEM
Air Conditioning System
Air Conditioner Pump
Air Conditioner Sea Strainer
Air Conditioner Thru-Hull
Raw Water Discharge
Air Conditioner V-Berth 12kw
Air Conditioner Dislpay
located at Power Management
Control Center
Shower Sump Box
Condensate Drain
Air Conditioner
Dislpay V-Berth
Air Conditioner Salon 16kw
Access from mid cabin
