Error Description
Table 6-8
Error code Description
Bat voltage high Battery voltage is high
Over Temperature Over temperature
Over Load Over load
Over Current Over current
MOV break MOV failed
Error: 101 M3 failed to communicate with DSP
Error: 102 The sample from M3 and DSP of the battery voltage is inconsistent
Error: 103 Buck over current
Error: 116 Reverse polarity protection diode failed
Error: 117 Bus Soft-start failed
Error: 118 DC-DC boot failed
Error: 119 DC injection outrange
Error: 120 Failed to detect current
Error: 121 Communication failed between DSP and M3
Error: 122 Bus voltage is too high
Error: 127 AC Output voltage is too high
Warn Description
Table 6-9
Item Description
Warn: Fan Warning Fan failed to turn
Warn: Bat Low Battery voltage low
Warn: Over Load Over load
Warn: Over Temp Over temperature
Warn: 103 Failed to read EEPROM
Warn: 104 Firmware version mismatched
Warn: 105 Failed to write EEPROM
