1.4 Basic System Architecture
Solar power
Generator
OR
Utility
External
Battery Packs
Home Appliances
Figure 1-1
As shown in above system diagram, the unit is used to power common house appliances including some
inductive load such as light, refrigerator. Also, diesel generator and power grid can be compensation in
which solar energy is insufficient as well as to charge the battery.
1.5 Product Overview
DEFGHNI
J K M L
A
B
C
O P Q
Figure 1-2
